Carlo Gavazzi Switching Power Supply AC/DC 480W 1-Phase 24V SPDC244801

Carlo Gavazzi Switching Power Supply AC/DC 480W 1-Phase, O/P: 24VDC 20A, Screw Terminal, Din-Rail.

The SPDC power supplies is a range where high performance meets high quality in a compact frame. These power supplies are offered in 120 W, 240 W, 480 W, and they have a universal input voltage range 85 VAC to 264 VAC and 130 VDC to 350 VDC. The SPDC achieve a high energy efficiency of up to 94% and can be connected in parallel to achieve twice the current. Reliability is guaranteed through the multiple integrated protections, and it also comes with built-in active PFC. SPDC coupled compact dimensions with advance features to provide a power supply for all automation applications requiring reliability, quality and performance.

Applications

The SPDC is extremely suitable for applications which requires high efficiency, high safety standards and high PF corrections. It also provides the DC OK signaling with LED and relay output.

Main functions

• High efficiency up to 93.8%
• In-built active PFC, PF>0.95
• Output options of 12 VDC, 24 VDC or 48 VDC.
• Universal input voltage range: 85 VAC to 264 VAC; 130 VDC to 350 VDC.
• Bi-colour LED for status, and DC-OK relay contact.
• Parallel function.

General Characteristics

• Reliable power in very compact dimensions. This SPDC has an ultra-slim DIN rail body, with up to 480 W in only 70 mm width of space.
• Built-in active PFC. The power factor correction (PFC)circuit adjusts the power factor to 0.99@110VAC and 0.95@230VAC.
• Parallel function. The SPDC can easily be connected in parallels to provide for increased power or used in redundancy operations.
• 150% Power Boost. The SPDC can provide 150% of the rated output power for up to 3 seconds, providing the extra power needed during critical startups.
• Universal AC, DC input range. SPDC Series can be powered with AC Voltage (85 VAC to 264 VAC) or with DC Voltage (130 VDC to 350 VDC).
• Reliable critical protection. Safety and reliability is guaranteed by the various output protections: Over Voltage (OVP), Over Load (OLP), Short Circuit (SCP) and Over Temperature (OTP).
• High efficiency and wide operating ambient temperature. The SPDC has a very high efficiency of up to 93.8%. The operating temperature range is, from -25°C to +60°C (without derating), and up to 70°C with -25% derating.
• Ease of installation. The SPDC can be installed in 5 different orientations, enabling the unit to fit easily into installation with limited space.
