Carlo Gavazzi Solid State Relay Contactor 1-Pole Zero-Cross, RN1A23D10E

Carlo Gavazzi Solid State Relay Contactor SOLITRON MINI 1-Pole Zero-Cross with Heatsink, Control: 5-32VDC, Operational: 120/230VAC, 10A, Contactor Layout.
The SOLITRON Mini Solid State Contactor is designed for industrial heating and motor applications. The Solid State Contactor is designed for DIN-rail and backplate mounting with integrated heatsink and overvoltage protection. The heatsink is moved to the back for optimal space-saving in the panel and easy wire mounting at the front of the relay. The limited current rating limits the need for optimal convection cooling as provided with Solitron 30, 50 and 63 A versions. The contactor elements are integrated on to the ceramic providing more than 4000 V insulation to the heatsink. AC or DC controlled versions are available with terminal layout as the standard for contactors or the US Mil-standard for Solid State Relays. Built-in LED status indication for applied control voltage.

General Characteristics

• AC Solid State Contactor in 22.5 mm housing
• Zero switching for heating and motor applications
• Rated operational current 10 A and 20 A
• Rated operational voltage 120/230 VAC, 400/480 VAC and 600 VAC
• Transient overvoltage protection
• LED-indication
• IP 20 protection
• DIN-rail and backplate mountable
• Terminal layout as contactor or SSR standard
• Insulation > 4000 V
