Carlo Gavazzi Timer Pulse Continuity Plug-In S114156230

Carlo Gavazzi Timer Pulse Continuity, Range: 0.15s-800s, Plug-In, SPDT, S Housing, Supply: 230VAC.

Pulse continuity, plug in control relay for monitoring e.g. movements of pistons or objects on a conveyor belt. Contacts or Namur sensor from selection of proximity switches may detect objects. 4 selectable time ranges and 2 selectable mode of operation.

General Characteristics

• 4 selectable time ranges: 0.15 s to 800 s.
• Knob adjustable time within range.
• Oscillator-controlled time circuit.
• Repeatability deviation: 1%.
• Direct connection for Namur sensor.
• Output: 10 A SPDT relay or 8 A DPDT relay.
• Plug-in type module.
• S-housing.
• LED-indication for relay and power supply on.
• AC or DC power supply.
