Carlo Gavazzi Timer Multi-Functions Front/Plug-In FMB01DW24

Carlo Gavazzi Timer Multi-Functions, 7 Functions, Range: 0.05s-300h, 48x48mm, Front or Socket, 11-Pin, DPDT, Supply: 12-240VAC/DC.

Multi-voltage timer with 7 functions and selectable time ranges from 0.05 second to 300 hours. 48 x 48 mm for front panel mounting and on 11-pin socket.

General Characteristics

• Time range 0.05 s to 300 h.

• Knob selection on time range.

• Knob-adjustable time setting.

• knob selection of operating mode (7 functions):

• Op - delay on operate.
• Rb - symmetrical recycler OFF first.
• R   - symmetrical recycler ON first.
• Id   - double interval.
• Dr  - delay on release.
• In   - interval.
• Io   - interval on trigger open.

• Manual start.

• Gate and reset inputs.

• Repeatability: ≤ 0.2% on full scale.

• Output: 8 A DPDT relay.

• 48 x 48 mm housing for front panel mounting.

• 11 pin socket.

• LED indication for relay status and power supply ON.
